Von Duprin AXPA98EO-26D Rim Exit Device, Exit Only, Push Bar Amour, CA accessible, Satin Chrome

Description

Von Duprin AXPA98EO Grade 1 Rim Exit Device, Wide Stile Pushpad, 36″ Device, Exit Only, Less Trim, CA-Accessible, Pushbar Armor, Hex Key Dogging, Satin Chrome Finish, Non-handed

98 Series Rim Exit Device

Heavy-duty high-performance exit devices with many customizable options.

Von Duprin’s 98 Series Exit Devices are wide-stile, heavy-duty push pads. They are certified to the maximum industry standards and are ideal for use in schools, hospitals and government buildings.

Specifications:

• Device functions: The device ships EO/DT/NL. Field selectable. For TP, K or L remove NL drive screw from device.
• Device lengths: 3′ 2’4′ to 3′ (711mm to 914 mm) Door size 4′ 2’10” to 4′ (864 mm to 1219 mm) Door size
• Device centerline from finished floor: 39 13/16″ (1011 mm) 39 11/16″ (1008 mm) with mullion
• Center case dimensions: 8″ x 2 3/4″ x2 3/8″ (203mm x 70mm x 60mm)
• Mechanism case dimensions: 2 1/4″ x 2 1/4″ (57mm x 57mm)
• Projection: Pushbar neutral – 3 13/16″ (97 mm) Pushbar depressed – 3 1/16″ (78 mm)
• Latch bolt: Deadlocking, 3/4″ (19mm) throw
• Fasteners & sex bolts (SNB): Includes screw pack for 1 3/4″ (44mm) and 2 1/4″ (57mm) thick metal or wood doors. Optional 425 SNB available
