3″ Hand Cup With T-Handle for Flat or Curved Surfaces
This compact hand cup has a 15 lbs [7 kg] lifting capacity for the accurate positioning of small flat or curved items. This hand cup can also be used as a mounting cup, with 1/4-20 threaded stud when its handle is removed.
Features:
- Fast attach and release
- Doubles as mounting cup – 1/4-20 threaded stud is exposed when handle removed
- Red-line indicator warns user of any significant vacuum loss
- Supplied with vacuum pad protector
| Model | TL3TH |
|---|---|
| SKU | 91154 |
| Load Capacity | 15 lbs [7 kg] |
| Surface Texture | Smooth |
| Material Porosity | Nonporous |
| Allowable Surface Curvature | Flat to Curved |
| Minimum Radius for Curved Loads | 4″ [102 mm] |
| Material and Ambient Temperature-Range | 32°F [0° C] up to 100° F [38° C] |
| Pad Diameter | 3″ [8 cm] |
| Pad Model | TL3 |
| Rubber Type | Standard |
| Handle Type | Industrial-Grade Plastic |
| Plunger Type | Industrial-Grade Plastic |
